with one head and two working platforms
- Features：
1. With double Y axis operating platforms, the operator can feed and receive materials alternately and feed materials continuously to save labor cost and improve production efficiency.
2. Simple replacement of the mold and accessories can be used for other products.
3. Double guide structure, wear-resistant and long life.
4. Standard servo electric batch, longer life, torque adjustment and speed are more convenient and flexible.
5. With intelligent detection function, it can detect missing lock, symbol lock, sliding tooth etc..
6. Drag and teach, and it’s more convenient and convenient to change the line.
| Model | KLD-531B12 | KLD-751B12 |
| Dimension (L*W*H) (mm) | 752*662*815 | 952*862*815 |
| Stroke of each axis (X*Y*Z) (mm) | 500*300*100 | 700*500*100 |
| Max locking product size (L*H) (mm) | 160*260 | 260*450 |
| Machine Weight (KG) | 80 | 110 |
| Drive mode | Closed loop step or servo | |
| Positioning accuracy | ±0.02mm | |
| Control system | Motion control card or Single chip microcomputer | |
| Screw conveyor | Suction | |
| Programming mode | Teach or map | |
| Locking time | 1~1.5S/PCS (screw) | |
| Programmer group storage qty | 1000 groups | |
| Communication interface | USB | |
| Power supply | AC 220V | |
| Power | 600W | |
| Air source (MPA) | 0.4~0.6 | |
| Electric batch | 1 | |
