| Model | Standard Version | Advanced Version |
| Feeder Capacity | Option 1: 29*8mm Option 2: 21*8mm+4*12mm+2*16mm | Option 1: 58*8mm Option 2: 42*8mm+8*12mm+4*16mm |
| Self-defined IC position | 20 PCS | |
| IC Tray position | 1 PCS | |
| Tube feeder | Integrated energy saving 5-tubes feeder *1 PCS (For free) | |
| Mounting head quantity | 2 PCS | |
| Mounting head control way | Mounting head controlled separately,Unbalanced swing arm mode | |
| Number of nozzle storage | 5 PCS (For free) | |
| Camera quantity | 4PCS ( 2 Laser aerial cameras+ 1 Mark camera+1 IC camera ) | |
| Light source configuration | Industrial grade area array light source+ Industrial grade ring light source | |
| Recognition capability | 0201 components~23*23mm IC(≥0.5 pitch)(Can be customized to recoginze 35*35mm IC) | |
| Mounting range | RC(0201,0402,0805,1201,1206) /LED/QFP/QFN /BGA etc. | |
| Placement rotation | 0-360° | |
| Mounting area | 300*360 (mm) | |
| Mounting height | ≤23mm | |
| Mounting speed | 6500CPH | |
| SMT standard reference | British system 0201 Package resistance 1200 CPH British system 3700 Package resistance 1200 CPH QFP 100 Pin chip 1000 CPH | |
| Material leakage detection | Laser detection+Vision detection | |
| XY axis motion control | Stepping servo motor + Grating ruler closed loop control | |
| Repeated positioning accuracy | ±35um | |
| Nozzle type | Compatible with Samsung CN030, CN040, CN065 etc. | |
| Feeder bank | Detachable feeder bank | |
| Support material type | Tape&Reel/Tube/IC Tray | |
| Feeder type | 8mm, 12mm, 16mm,24mm | |
| Operating system | Linux | |
| Programmatically | Computer coordinate file import/Manual coordinate file editing, Support off line programming | |
| Net weight | 70KG | 77KG |
| Power | 200W | |
| Power supply | AC110V/AC220V | |
| Machine dimension | L900*W780*H540 (mm) | |
| Display screen | 10.1 inch | |
| Keyboard and mouse | Yes | |
